Control box
| Temperature range | from -5°C to +40°C |
|---|---|
| Capacitor | from 16µF to 80µF |
| Fastening | wall fastening with hole 4,2x6,5 |
| Switch | Bipolar 0/I |
| Power | from 0,25kW to 2,2kW |
| Frequency | 50 Hz |
| Power supply voltage | 1x220-230V ±5% |
| Cable gland size | M20x1.5 |
| IP protection class | IP55 |
| Gasket to be added | No |
| Cable glands | Yes |
| Number of cable glands | 2 |
| UL listed | No |
| Raw material | ABS + Thermoplastic Rubber |
| Color | Grey RAL7035 |
| Thermal protection | from 4A to 18A |
Description
Protection and control panel for submersed electric pumps and motors.
